| Machine Alignment Capability @ 2.0 CmK | +/- 12.5 μm | +/- 12.5 μm |
| System Alignment Capability @ 2.0 CmK | +/- 20 μm | +/- 15 μm |
| Wet Print Capability @ 2.0 CpK – AVS Certified | +/- 25 μm | +/- 20 μm |
| Core Cycle Time | 8 sec | 6,5 sec |
| Standard Transport System | Single stage | 3 stage |
| Under Stencil Cleaner (USC) | IUSC (Cyclone optional) | Cyclone |
| USC Side channel blower vacuum system | 25 Litre/min | 35 Litre/min |
| Side clamping (snugger) | Option | Option (single stage) |
| All Purpose Clamping (APC) | Option | Option* |
| Verification max. 750mm²/sec | Option | |
| Verification max. 1700mm²/sec | Option | Standard |
| Grid-Lok® | Option | Option |
| Stinger | Option | Option |
| Verification & Traceability | Option | Option |
| Close loop to SPI (ProDEK) | Option | Option |
